High Elongation HTE Rolled Annealed Copper Foil 0.035mm High Thermal Endurance

Name: High Elongation HTE Rolled Annealed Copper Foil 0035mm High Thermal Endurance
Brand: ED-JIMA
Price: 13 USD

Brand Name : ED-JIMA

Model Number : EDMCCL

Certification : SGS, ISO,Reach, RoHS

Place of Origin : CHINA

MOQ : 150kgs

Price : USD13~19/kgs

Payment Terms : T/T, L/C

Supply Ability : 1200 per month

Delivery Time : 7-15days

Packaging Details : wooden box

Thickness : 35um，0.035mm，1oz，35micron

Standard : IPC-4562

Peel strength : above1.7kg/cm

Weight range : 100~ 500kgs，or custom

Shape : roll

performance : High thermal endurance

Contact Now

Product Description

High elongation electrolytic copper foil 0.035mm with high thermal endurance for MCCL copper foil ipc-4562

	1.The treated foil in gray or red
	2.High peel strength
Features	3.Good etch ability
	4.Excellent adhesion to etching resist
	5.Anti foil cracking by high elongation at elevated temperature
	6.Eco-friendly products and processes
	7.High temperature elongation
	8.High thermal endurance

Application	1.PCB board,pcb
	2.Antennas pcb
	3.Metal Copper Clad Laminate
	4.MCCL
	5.CCL,Copper Clad Laminate

Electrolytic copper foil shows:

High Elongation HTE Rolled Annealed Copper Foil 0.035mm High Thermal Endurance

Mill Test Certificate of High temperature elongation ED copper foil

Thickness		um	12	18	35	70	IPC-TM-650 2.3.12
Area weight		g/m²	107±10	153±15	305±30	610±61	IPC-TM-650 2.2.12
Roughness	(RA)	μm	<0.43	<0.43	<0.43	<0.43	IPC-TM-650 2.2.17
Roughness	(RZ)	μm	<7	<8.0	<10.0	<14	IPC-TM-650 2.2.17
Copper≥		%	Above99.8				IPC 4562 2.3.15
Tensile Strength	State normal	kg/mm2	>21	>21	>28	>28	IPC 4562 2.4.18
Tensile Strength	State temper (180℃)		>15	>15	>15	>15	IPC 4562 2.4.18
ElongationI	state normal	%	>3.0	>4	>5	>5	IPC 4562 2.4.18
ElongationI	state temper (180℃)	%	>2	>2	>3	>3	IPC 4562 2.4.18
Peel strength		kg/cm	>1.1	>1.3	>1.7	>1.9	IPC 4562 2.4.8
High temperature oxidation resistance(225℃, 10min)		No color change					CCP Standard
Solderability		Good					CCP Standard
Splice		≤2					CCP Standard

Remark:

1. Standard Width is1295(±1)mm,Max width is 1380mm,May according to the customer request tailor.

Package of ED electrolytic copper foil :

RFQ:

Q1: What's your guarantee?

A: All our products have 6 months guarantee after received goods, if any quality problem can contact us.

Q2: What's your delivery time ?

A: The common delivery time is 5-30working days. The specific delivery time depends on the items and the quantity of your order.

Q3. Can you cut into small size?
Yes, we can.

Q7.It is wooden box?
Yes ,it is .

Q8: Can you supply the sample?

A: We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.or we also provide A4 Sample

Q9. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q4. Is it possible be zinc free copper foil?
Yes ,it is possible.

Q5.It is wooden box?
Yes ,it is .

Q6. Can we come to China visit factory ?
Yes ,you can .
